The company is equipped with entire gamut of sub surface investigation instruments & machinary’s and offers integrated solution to any green/brown field projects right from site selections to DPR level investigation. The lists of a few of the facilities available with the company are listed below.
Pipe Line Route Survey
Core Drilling with a Hydraulic Rig
Geophysical Resistivity Survey
DGPS Survey
Excavated Pit
Geotechnical Boring/Drilling with Shell cum Rotary Core Drilling Rig
Recovered core samples in a Core Box
UDS tube filled with samples
Total Station Survey
Chemical Analysis of ores by XRF Analyzer
Samples in SPT tube
Consolidated undrained test
Sample Extraction from UDS tube
Rock Sample test
Unconfined Compression Test
Carry Forward of RL from SOI bench mark
Non core drilling by a DTH rig for dug well for Pump Out Test
SURVEY
Sl. No.
Instruments
1
SPS 855 DGPS with Glonass
2
Hand held GPS
3
Total Stations with Prisms, Reflectors & Accessories
4
Digital Level
5
Auto Level
6
1″ digital Theodolites
7
Echo-sounder
8
Various survey implements & tools
Geotechnical, Geophysical & Geological Investigation
Sl. No.
Name of Equipments/Instrument
1
Shell cum mechanically operated rotary diamond core drilling rig with accessories for boring in soil (6″ dia hole) & drilling in rock (NX size)
2
Skid mounted Heavy Duty Diamond Core Drill Machine, Hydraulic feed, with all accessories capable of drilling up to a depth of 200 m (NX size), 80m (HX size)
3
Heavy Duty Diamond Core Drill Machine, Hydraulic feed, with all accessories capable of drilling up to depth of 350 m (NX size), 100m (PX size)
4
Double winch operated Wire line, diamond Core Drill Machine, Hydraulic feed, with all accessories capable of drilling up to depth of 300m (NQ, HQ & PQ sizes)
5
Truck mounted Down the Hole (DTH) rig for collection of low cost non core samples & for well drilling fitted with air compressors & accessories for hole sizes renging from 5″-14″ diameter, up to a depth of 300m
6
Mud pumps, Centrifugal pumps, Triplex pumps, Submersible pumps etc.
7
Spring Balance, Core Splitter, Thin wall samplers, Split spoon samplers, Mechanical Sieve Shaker, Mortar & Pestle and other sampling devices
8
In situ geotechnical testing instruments e.g Plate Load Test, Field CBR , Packer Test, SCPT etc.
9
DC Resistivity meter & accessories having capacity in hard rock upto 200m depth and in clay/sand up to 150m depth
10
Geological implements/ tools e.g Geological hammer, Clinometers, Brunton Compasses , Pocket lenses, Hand augur etc.
GEOTECHNICAL INVESTIGATION
General Physical Tests on soil & rock samples
Volumetric analysis of elements & radicals
XRF analyzer
Determination of engineering properties of Soil
Thin section study under Petrologic Microscope
Determination of rock properties
Aggregate testing
